SCD 046-029-060 ACP5N IC908
DIN 6537 solid carbide drills with coolant holes, drilling depth 5xD.
Termékadatok
| Drill Bit Size / Cutting Diameter (DC) | 4.6 mm | Minőség | IC908 |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 4.6 mm | Mérés típusa | Metric |
| Bevonat | TiAlN | Usable Length (LU) | 29 mm |
| Alkalmazható anyag | | Acél | Rozsdamentes acél | Öntöttvas | Kemény anyagok | Erősen ötvözött hőálló acélok | | Length Chip Flute (LCF) | 37 mm |
| Alkalmazás | | Fúrás | | Overall Length (OAL) | 74 mm |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Flute Count (NOF) | 2 |
| Coolant Supply Property (CSP) | Coolant Thru | Cutting Direction (HAND) | Right Hand |
| Number of Teeth | 2 | Test anyaga | Carbide |
| Shank Length (LS) | 35 mm | Connection Code Machine Side (CCMS) | Cylindrical |
| Forgácsolóél anyaga | Carbide | Shank Diameter Tolerance (TCDMM) | h6 |
| Tool Type | solid carbide Drills | Egység | M |
Termékjellemzők
| Termékcsalád | DIN 6537 solid carbide drills with coolant holes, drilling depth 5xD. | COO | Korea |
Shipping Info
Csomag súlya
0.0230
